COMPONENTS

TECHNICAL SPECS

• Frame

  Dusty Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.

  Sizes

  S: 440mm / M: 460mm / L: 500mm / XL: 530mm

• Fork

  Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork

  Headset

  OnOff gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

• Stem

  OnOff gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S: 70mm M: 70mm, L: 80mm, XL: 90mm

  Handlebar

  OnOff Barium gravel 18º bar flare. Width sizes S/M: 440mm, size L/XL: 460mm

• Grips

  Barium gravel dark grey

  Seatpost

  OnOff Barium gravel microadjust diameter 27.2mm, length 400mm

• Saddle

  FIZIK Terra Argo X7 150mm

  Front brake

  Sram Rival 1, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

• Rear brake

  Sram Rival 22, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

  Brake lever

  Sram Rival, tooled reach adjust, aluminum levers

• Rims

  MDK-XG1, 23mm internal width, tubeless ready, 28 spokes

  Spokes

  CN round stainless steel

• Front hub

  Novatec D041, Boost 12x100mm, sealed bearings, IS 6 bolts

  Rear hub

  Mahle X20 Drive Unit, HG freehub

• Front tire

  Maxxis Rambler 700x40, tubeless ready, dual compound EXO protection, 60 TPI, folding bead, tan wall

  Rear tire

  Maxxis Rambler 700x40, tubeless ready, dual compound EXO protection, 60 TPI, folding bead, tan wall

• Crankset

  Sram Rival 1 DUB GLS DUB Wide, S: 170mm, M: 172,5mm, L: 172,5mm, XL: 175mm.

  Rings

  Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide,

• Bottom bracket

  Mahle pressfit, sealed bearings, w/ torque sensor

  Chain

  Sram PC-1110, 11s, Powerlock

• Rear derrailleur

  Sram Rival 1, 11s

  Shift levers

  Sram Rival 1 11s, Exact actuation

• Casette

  Sram XG-1150 10-42T, 11s

  Others

  *Optional range extender: Mahle e185 , 172Wh

• Weight

  12.8 kg

  Display

  Pulsar One Wireless

• Motor

  Mahle X20 Drive Unit

  Battery

  Mahle X20 IX350Wh
