COMPONENTS

TECHNICAL SPECS

• Frame

  Dusty Stealth Air Carbon, pressfit 386 EVO bottom bracket, tapered head tube, HHG internal cable routing, integrated internal non-removable battery, 12x142mm rear axle, 1X or 2X drivetrain design, Flatmount brake compatible, integrated dropout speed sensor.

  Sizes

  S: 440mm / M: 460mm / L: 500mm / XL: 530mm

• Fork

  RockShox Rudy Ultimate, 40mm travel, 12x100mm maxle stealth, 45mm offset

  Headset

  OnOff gravel tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

• Stem

  OnOff gravel 6061 T6 Alloy, 31.8mm barbore, rise: +/-7º, length: sizes S: 70mm M: 70mm, L: 80mm, XL: 90mm

  Handlebar

  OnOff Barium gravel 18º bar flare. Width sizes S/M: 440mm, size L/XL: 460mm

• Grips

  Barium gravel dark grey

  Seatpost

  RockShox Reverb XPLR AXS 75mm wireless 27.2X400mm dropper post

• Saddle

  FIZIK Terra Argo X7 150mm

  Front brake

  Sram Force Etap AXS 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

• Rear brake

  Sram Force Etap AXS, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad

  Brake lever

  Sram Force, contact point adjustment, tooled reach adjust, plastic levers

• Rims

  Mavic Allroad Pro Carbon SL Disc, UST, 23mm internal width, hookless, 28 spokes

  Spokes

  Steel double butted flat spokes

• Front hub

  Mavic, 12x100mm, IS 6 bolts

  Rear hub

  Mahle X20 Drive Unit, XDR freehub

• Front tire

  Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead

  Rear tire

  Maxxis Rambler 700x45, tubeless ready, dual compound EXO protection, 120 TPI, folding bead

• Crankset

  Sram Force 1 Carbon GLS DUB Wide, S: 170mm, M: 172,5mm, L: 172,5mm XL: 175mm.

  Rings

  Sram X-Sync Eagle 40T direct mount, alloy, narrow-wide,

• Bottom bracket

  Mahle DUB pressfit, sealed bearings, w/ torque sensor

  Chain

  Sram NX Eagle, 12s, Powerlock

• Rear derrailleur

  Sram X01 Eagle AXS, Type 3 roller bearing clutch, cage lock, 1x12s

  Shift levers

  Sram Force Etap AXS 12s, single click

• Casette

  Sram XG-1275, 10-52T, 12s

  Others

  *Optional range extender: Mahle e185 , 172Wh

• Weight

  13.8kg

  Display

  Pulsar One Wireless

• Motor

  Mahle X20 Drive Unit

  Battery

  Mahle X20 IX350Wh
